Butom
190cc Carburetor Kit for Toro 22-Inch Recycler

Push Mowers · Carburetors

Butom 190cc Carburetor Kit for Toro 22-Inch Recycler

4.6 out of 5 · 741 reviews

Complete carb kit for Toro Recycler 22 mowers on 190cc engines.

$19.99at last check, Sep 27, 2026

Fits

  • Toro 20332
  • Toro 20334
  • Toro 20331
  • Toro 20333
  • Toro 20092
  • 126T00
  • 124T02
  • JD JS63

Replaces

  • 799866
  • 799871
  • 790845
  • 796707
  • MIA11798

About this part

The Toro 22-inch Recycler is a workhorse, and after a few seasons its carburetor is usually the reason it won't start on the first pull. This kit is built around the 190cc engine found on the 20330 to 20352 range and many older Recyclers besides.

Because the air filter, gaskets, fuel filter and plug are in the box, you can service the whole intake side of the engine in one sitting. The same carb also fits a long list of John Deere JS and JA walk-behinds that share the engine.

  • Matched to Toro Recycler 22 models from 20064 to 20352
  • Also fits 122000, 124000 and 126000 series engines
  • Air filter, gaskets, fuel filter and plug included
  • Cross-fits many John Deere JS and JA walk-behind mowers
In the box
  • Carburetor
  • Air filter
  • Gaskets
  • Fuel line & filter
  • Spark plug
Specs
Engine190cc vertical shaft
Series122000 / 124000 / 126000
Before you order

Compare the stamp on your old part with the “Replaces” list, and your engine code with “Fits”. If it still isn't clear, send a photo to the counter and we'll check it for you.
