591137 Carburetor for Troy-Bilt Pressure Washers

Engines & Washers · Carburetors

Butom 591137 Carburetor for Troy-Bilt Pressure Washers

4.4 out of 5 · 307 reviews

Carb for 190cc 775EX–875EXi engines on 2700–3000 PSI washers.

$12.09at last check, Sep 27, 2026

Fits

  • 775EX
  • 850EX
  • 875EX
  • 875EXi
  • Troy-Bilt TB350-XP
  • Toro TimeMaster 30"

Replaces

  • 591137
  • 590948
  • 593599
  • 595390
  • 594287
  • 799248

About this part

A pressure washer sits for months with fuel in it, and its carburetor pays for that every spring. This 591137 carb fits the 190cc 775EX to 875EXi engines used on 2700, 2800 and 3000 PSI washers from Troy-Bilt and others.

The mounting holes sit 46 mm apart on the throttle side and 35 mm on the choke side, a quick way to confirm the fit. It also fits the Toro TimeMaster 30-inch mower.

  • Fits 190cc 775EX, 850EX and 875EXi engines
  • For 2700–3000 PSI pressure washers
  • Three gaskets and an O-ring included
  • Brass parts, zinc-plated bowl
In the box
  • Carburetor
  • 3 gaskets
  • O-ring
Specs
Throttle-side holes46 mm
Choke-side holes35 mm
Engine190cc
Before you order

Compare the stamp on your old part with the “Replaces” list, and your engine code with “Fits”. If it still isn't clear, send a photo to the counter and we'll check it for you.
